Description
Frameset
Frame
OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel
Fork
RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock
RockShox Deluxe Select+ RT, 205 mm x 60 mm
Max compatible fork travel
160mm (575mm axle-to-crown)
Wheels
Wheel front
Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Wheel rear
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Tyre
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29×2.50″
Max tyre size
Frame: 29×2.50″, Fork: See manufacturer
Drivetrain
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, long cage
Crank
E*thirteen E*spec Plus, 165 mm length
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Max. chainring size
1x: 34T, min 30T
Components
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: S
TranzX JD-YSI-22PLQ, 100 mm travel, internal routing, 34.9 mm, 346 mm length
Size: M
TranzX JD-YSI-22PLQ, 150 mm travel, internal routing, 34.9 mm, 454 mm length
Size: L, XL
TranzX JD-YSI-22PLQ, 170 mm travel, internal routing, 34.9 mm, 497 mm length
Handlebar/stem
Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Brake
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Brake rotor
Shimano RT66, 6-bolt, 203 mm
Rotor size
Max brake rotor sizes – Frame: 203mm, Fork: see fork manufacturer
Accessories
Battery
Weight
Weight
M – 19.93 kg / 43.94 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
